An enthusiast has created a refined version of a voltmeter clock, featuring a cleaner design and continuous motion display. The project uses inexpensive panel meters and custom-machined parts, showcasing accessible electronics craftsmanship.
An individual has developed a redesigned voltmeter clock that features a more attractive appearance and improved functionality, using three inexpensive panel voltmeters and custom-machined wooden parts. This project highlights accessible electronics and craftsmanship, making it notable for hobbyists and tech enthusiasts.
The project began as a personal initiative to improve upon an earlier voltmeter clock built in 2019. The creator disassembled three generic 90° panel voltmeters from Amazon, measuring and customizing their faces with printed decals to display hours, minutes, and seconds. Unlike previous designs, this version incorporates continuous motion for the hands, achieved through software-controlled pulse signals rather than traditional step movements. The clock’s enclosure was crafted from machined wood, with internal notches allowing a curved sidewall to be shaped without specialized jigging. The circuit uses an AVR128DB28 microcontroller powered by a wall wart, with simple digital outputs controlling the meters via pulse-width modulation, eliminating the need for complex analog components. The entire build emphasizes affordability, with components costing around $9 per meter, and a focus on aesthetic refinement, including hiding the meter flanges behind recessed patterns.
Why It Matters
This development matters because it demonstrates how accessible electronics and craftsmanship can produce a functional, visually appealing clock using inexpensive parts. It offers a practical example for hobbyists interested in combining analog gauges with digital control, and highlights a creative approach to integrating electronics with custom woodworking. The project also shows how simple microcontrollers can control analog devices effectively, encouraging more DIY innovations in clock design and display technology.
