TL;DR
TSMC, Intel, and Samsung have revealed their upcoming process technology roadmaps, including mass production of 2nm chips. Intel’s roadmap is the most aggressive, while Samsung focuses on yield improvements. These plans impact the future of high-performance computing and chip manufacturing.
TSMC, Intel, and Samsung have all announced the commencement of mass production using 2nm-class process technology, marking a significant milestone in semiconductor manufacturing. These developments position the three industry leaders at the forefront of advanced chip fabrication, with implications for high-performance computing, AI, and consumer electronics.
In December 2025, TSMC began high-volume manufacturing of chips using its N2 process at two Taiwan fabs, emphasizing predictable scaling and specialized nodes for high-performance and cost-effective applications. Samsung initiated production with its SF2 node, which is considered a 2nm-class process, around mid-2025, but faces yield challenges that limit its broader adoption. Intel followed in November with its 18A node, primarily at development lines in Oregon, focusing on integrating GAA transistors and PowerVia backside power delivery network (BSPDN), with plans for high-volume production by 2027-2028.
Intel’s roadmap is notably ambitious, aiming to introduce 14A and 14A-E nodes featuring second-generation RibbonFET GAA transistors and high-NA EUV lithography, with early adoption by external partners like Musk’s Terafab project. Meanwhile, Samsung’s focus remains on yield improvement, with iterative node updates and efforts to stabilize its GAA process technology, which has yet to see widespread high-volume adoption.
Why It Matters
This technological progression is critical for the future of computing, enabling faster, more power-efficient chips for AI, data centers, and consumer devices. Intel’s aggressive roadmap could redefine performance benchmarks, while TSMC’s focus on predictable scaling supports a broad range of high-performance and specialized applications. Samsung’s emphasis on yield stability impacts its competitiveness in the high-end process market.
